AD9850 DDS Signal Generator Module

KSh 3,300.00

AD9850 DDS Signal Generator Module in Electronic Modules

Description

Description

AD9850 DDS Signal Generator Module IC Test Equipment 0-40MHz Sine Square Wave

Product features
AD9850: 0-40Mhz
When the frequency after 20-30Mhz, Harmonic is getting bigger and bigger, The waveform will become increasingly unclean
Square wave: 0-1Mhz
The 70-MHz low-pass filter makes the SN ratio of the waveform better
The comparator reference input voltage is generated by the variable resistor, adjust the resistance can be different duty cycle square wave
 Product description

AD9850 DDS Signal Generator Module IC Test Equipment 0-40MHz Sine Square Wave

Product Information:
AD9850 is produced by DDS module which be most widely used in ADI
This module can output sine wave and square wave, two sine wave and two square wave output
AD9850: 0-40Mhz
When the frequency after 20-30Mhz, Harmonic is getting bigger and bigger, The waveform will become increasingly unclean
Square wave: 0-1Mhz
The 70-MHz low-pass filter makes the SN ratio of the waveform better
The comparator reference input voltage is generated by the variable resistor, adjust the resistance can be different duty cycle square wave
The AD9850 module uses a 125MHz active crystal
Note:
In the case of output sine wave, the output of the square wave to the IO port, directly adjust the blue potentiometer can output square wave.

Package Includes:
1 x AD9850 DDS Signal Generator Module IC Test Equipment 0-40MHz Sine Square Wave
